D-Sub (VGA)

D-Sub (VGA) Connector｜Classic Analog Video Transmission Interface

Product Overview

D-Sub (D-Subminiature) is a widely used interface for transmitting analog video signals. The most representative application is VGA (Video Graphics Array), commonly found in computer graphics cards, monitors, and projectors. Characterized by its D-shaped shell and multi-pin design, the connector provides a stable mechanical structure and reliable contact performance.

Common Types and Applications

Type	Specification	Application
9 Pin (DE-9)	Compact, often used for serial communication	Industrial control, legacy computer interfaces
15 Pin (DE-15/VGA)	Most common, three-row pin layout	Computer monitors, projectors, graphics cards
25 Pin (DB-25)	Larger, multi-purpose	Printers, industrial equipment, communication interfaces
High-Density	Short-body or high-density pin arrangement	Space-saving, suitable for precision equipment

Technical Features

Analog Signal Transmission: Supports RGB video signals, ideal for traditional display devices
Durable Shell Design: Metal shielding enhances anti-interference capability
Multiple Pin Configurations: Available in 9, 15, 25 pins to meet diverse requirements
Flexible Mounting Options: DIP, SMT, right-angle, and vertical packages
High Reliability: Designed for repeated insertion, suitable for long-term use

Application Scenarios

Computers & Display Equipment: Monitors, projectors, graphics cards
Industrial Control: PLCs, machinery communication interfaces
Peripheral Devices: Printers, legacy communication equipment
Special Applications: High-density versions for space-constrained industrial or military-grade devices
